n Validation support information group [VALIDATION]
Name Function Ref.
DATE Displays or set the date. P.53
TIME Displays or set the time. P.53
MEMORY CHECK Checks ROM/RAM. P.54
LEAK SENSOR CHECK Checks operation of the leak sensor. P.54
PULSE CHECK Checks the pulse. P.55
FLOW CHECK Checks the flow rate. P.56
PRESS LIMIT CHECK
Checks that the maximum and minimum pressure
functions work correctly.
P.60
n Calibration support information group [CALIBRATION]
Name Function Ref.
Input PASSWORD
*1
Input a password. P.61
OPERATION MODE
Not used in CL model.
*2
-
DATE FORMAT Changes the displayed order of year, month and day. P.62
INITIALIZE PARAM Initializes parameters. P.62
PARAMETER LOCK To prohibit change of parameters. P.62
PARTS MGMT TOOL Sets the usage of the parts management tool. P.63
PASSWORD SETTING Changes the password. P.63
CBM PARAMETER
Displays or set the parameters of the connected system
controller.
P.64
LEAK THOLD Sets the operation level of the leak sensor. P.66
FLOW COMP FACTOR
Not used in CL model.
*2
-
PRESS COMP FACTOR
Not used in CL model.
*2
-
PLUNGER SEAL Sets the time to replace the plunger seal. P.68
P.MAX OVERRIDE Sets override of the maximum pressure. P.68
SV SELECT
Not used in CL model.
*2
-
AUTO DIAGNOSTICS Turns on/off Auto-Diagnostics. P.68
* 1 In the calibration support group, an invalid password prevents the user from going further than
[OPERATION MODE] even if the user presses [Enter].
* 2 Do not change the factory default value.
48
LC-40D X3 CL LC-40D XR CL
3 Operation
