SICK FLOWSIC100 User Manual

Start-up and Parameter Settings
FLOWSIC100 · Operating Instructions · 8012513/YSA5/V 2-1/2016-07 · © SICK Engineering GmbH 129
Subject to change without notice
Fig. 102 Basic parameters
For small duct dimensions < 0.5 m (short measuring paths), take the thick-
ness of the seals used into account when determining measuring path L.
F
-
F
N
L
L

A2
A1
Di

L
2
N
L
F
2
L
1
F
1
FLSE100 A
FLSE100 B
Cross-sectional area:
Circular ducts: Rectangular ducts:
A =
· Di² A = a · b
Cross-sectional changes
A =
Measuring path length:
L = FF - 2 · NL
FF = F1 + F2
L = L1 + L2 = (F1 + F2) - 2 · NL

4
A1 + A2
2
