Start-up and Parameter Settings
FLOWSIC100 · Operating Instructions · 8012513/YSA5/V 2-1/2016-07 · © SICK Engineering GmbH 117
Subject to change without notice
4.1.3.2 Connecting to the device via the “Device family” mode (recommended search settings)
1 Click “Search settings”.
2 Select search mode “Device family oriented search” and click “Next”.
Fig. 86 Selecting the search mode
3 Select device family “MCU” and click “Next”.
Fig. 87 Selecting the device family
4 If devices are to be connected via Ethernet, configure the IP addresses:
Click “Add”.
NOTICE:
MCU(P) does not support automatic recognition of IP addresses (SICK AutoIP),
the IP addresses therefore have to be configured manually.
An IP address specified by the customer is entered at the factory when the
address is available when the device is ordered. If not, standard address
192.168.0.10 is entered.
To change the IP address, see
p. 151, §4.3.6.
