Assembly and Installation
FLOWSIC100 · Operating Instructions · 8012513/YSA5/V2-1/2016-07 · © SICK Engineering GmbH 87
Subject to change without notice
3.3.4 Installing optional sets for emergency air supply for devices with purge/cooling air
operation
3.3.4.1 Emergency air supply for device types M-AC and H-AC
The " emergency air supply FLOWSIC100 M-AC and H-AC“ is delivered pre-assembled in its
subassemblies. (
 p. 87, Fig. 56)
Fig. 56 Primary pressure set and resulting cooling air volume flow
Fig. 57 Layout and functional diagram of cooling air supply with emergency air option
Emergency operation with compressed air
Compressed air primary pressure [bar]
Volume flow [m3/h]
Air
inlet
Air outlet
Compressed
air connection
