Start-up and Parameter Settings
Subject to change without notice
4.2.3 Setting the check cycle parameters
 Open the device file"MCU" and enter the Level 1 password (  p. 125, Fig. 99).
 Set the maintenance mode (
 p. 127, §4.2.1).
Define the check cycle output in the "Adjustment/Function Check - Automatic" menu (
 Fig.
103). The function check can also be started manually.
Fig. 103 "Adjustment/Function Check - Automatic" menu
Field Parameters Remark
Output duration of
function control
value
Value in seconds Output duration of the check value
Function check
interval
Time between two check cycles
 p. 47, §2.5
Span for control
point
Value in % between 50% and
70%
 p. 48, §2.5.2
Function Check
Start Time
Hour
Defining a start timepoint in hours and
minutes.
Minute
