134 FLOWSIC100 · Operating Instructions · 8012513/YSA5/V2-1/2016-07 · © SICK Engineering GmbH
Start-up and Parameter Settings
Subject to change without notice
4.2.6 Setting the damping time
The damping time can be configured in the MCU directory ‘‘Configuration / Value Damping”
(
Fig. 106).
Fig. 106 ‘‘Value Damping” submenu
4.2.7
Data backup
All parameters relevant for the collection, processing and input/output of measured values
and current measured values can be saved and printed. This simplifies reentering set
device parameters (e.g. after a firmware update) as well as registering device data or
device states for diagnostic purposes.
The following options are available.
● Saving as project
Saving the data as a project allows saving not only device parameters but also data
logs.
● Saving as protocol
Device data and parameter are recorded In the parameter protocol.
A diagnosis protocol can be generated for analyzing the device function and to identify
possible malfunctions.
Field Parameters Remark
Damping time
Sensor 1
Value in s
Damping time for the selected measured variable (
p. 46,
2.4.3)
Damping time
Sensor 2
Value in s
Damping time of additional sensors connected to the control
unit (bus wiring)
