Start-up and Parameter Settings
FLOWSIC100 · Operating Instructions · 8012513/YSA5/V 2-1/2016-07 · © SICK Engineering GmbH 137
Subject to change without notice
Example of a Parameter protocol
Fig. 110 MCU parameter protocol (example)
MCU Parameter Protocol - FL100 2 Path
Device Type: MCU
Mounting Location: SICK
7/22/14 10:56 AM Page 1/1
Device Information
Device Type MCU
Serial Number 00004711
Ident Number 00000
System Ti me 08 Nov 2009
22:03:46
Firmware Version 01.08.00
Hardware Version 1.5
Bootloader Version 00.99.xx
Calculation Values
Sources
Temperature Source Analog Input 1
Pressure Source Analog Input 2
Moisture Source Constant Value
Constants
Temperature Constant 20.00°C
Pressure Constant 1013.25mbar
Moisture Constant 50.00%
Adjustment
Function Check Interval 8 hours
Function Check Output Duration 90s
Output Check Results on AO yes
System Configuration
Number of external AO 0
Number of external AI 0
Serial Exp ansion Module Ethernet
Serial Expansion Module
Type Ethernet 10BaseT
Profibus Address 126
Modbus Address 1
IP Address 010.133.082.001
Subnet Mask 255.255.248.000
Gateway 000.000.000.000
TCP Port 2111
I/O Configuration
Analog Output General Settings
Error Current Selection yes
Error Current Value 21 mA
Maint. Current Selection User defined value
Maint. Current Value 0.50mA
Span Value 70%
Analog Output 1
Live Zero 4mA
Limit Low 0.50
Limit High 1.87
Calibration factor CC0 0.0000
Calibration factor CC1 171.0000
Calibration factor CC2 0.0000
Source Velocity of Gas (avg)
Analog Output 2
Live Zero 4mA
Limit Low -100.00
Limit High 100000.00
Source Volume flow s.c. dry
(avg)
Analog Output 3
Live Zero 4mA
Limit Low -20.00
Limit High 20.00
Source Velocity of Gas (avg)
Analog Output 4
Live Zero 4mA
Limit Low 0.00
Limit High 1.00
Source Not Used
Analog Output 5
Live Zero 4mA
Limit Low 0.00
Limit High 1.00
Source Not Used
Analog Input 1 (Temperature)
Limit Low 0.00°C
Limit High 200.00°C
Calibration factor CC0 0.0000
Calibration factor CC1 0.0204
Calibration factor CC2 0.0000
Analog Input 2 (Pressure)
Limit Low 0.00mbar
Limit High 1100.00mbar
Calibration factor CC0 0.0000
Calibration factor CC1 0.0204
Calibration factor CC2 0.0000
Analog Input 3 (Moisture)
Limit Low 0.00%
Limit High 0.00%
Limit Switch
Source Velocity of Gas (avg)
Limiting Value 1.87
T90 Time
T90TimeFLPath1 1.0s
T90TimeFLPath2 1.0s
