94 FLOWSIC100 · Operating Instructions · 8012513/YSA5/V2-1/2016-07 · © SICK Engineering GmbH
Assembly and Installation
Subject to change without notice
Fig. 66 Connection for operating voltage 380 V AC with phase sensor for monitoring failure of any phase
Purge air unit
Motor circuit breaker
(onsite)
Junction box
Purge air blower
Solenoid valve *)
*) In SICK scope of delivery but not fitted
Phase sensor
(onsite)
