SICK S300

Operating instructions Chapter 12
S300
8010948/YY96/2016-02-17 © SICK AG • Industrial Safety Systems • Germany • All rights reserved 123
Subject to change without notice
Technical specifications
Minimum Typical Maximum
Measurement error on data output via RS<422
(S300 Long Range up to 3 m in the specified
remission range)
Systematic error ±20 mm
Statistical incl. systematic errors
at 1  ±29 mm
at 2  ±38 mm
at 3  ±47 mm
at 4  ±56 mm
at 5  ±65 mm
Evenness of the scan field at 2 m ±50 mm
Distance from mirror axis of rotation (zero
point on the X and Y axis) to the rear of the
device
55 mm
Distance between centre of the scan plane
and the bottom edge of the housing
116 mm
Warning field
24)
8 m
Distance measuring range 30 m
Number of multiple samplings (configurable
via CDS)
2 16
Power-up delay
Of a configured device 15 s
If the configuration is read from the system
plug
25 s
Restart after (configurable) 2 s 60 s
Basic response time 80 ms
24)
The detection capability of the warning field is dependent on the remission of the objects to be detected (see
section 12.1 on page 116).
