SICK S300

Chapter 12 Operating instructions
S300
124 © SICK AG • Industrial Safety Systems • Germany • All rights reserved 8010948/YY96/2016-02-17
Subject to change without notice
Technical specifications
Minimum Typical Maximum
Electrical data
Supply voltage (SELV)
2
5)26)
16.8 V 24 V 30 V
Permissible residual ripple
2
7)
±5 %
Switch on current
28)
2 A
Operating current without output load
29)
0.25 A 0.33 A
Operating current with max. output load
29)
1.7 A
Power consumption without output load
2
9)
6 W 8 W
Power consumption with maximum output
load
2
9)
41 W
Power consumption in the stand-by mode or
park mode without output load
2
9)
6 W 8 W
Electrical connection System plug with screw terminal
connections
Technical specifications, screw type terminal
FE
Cross-section of rigid cores 0.3 mm² 1.6 mm²
Cross-section of flexible cores
3
0)
0.3 mm² 1.6 mm²
American Wire Gauge (AWG) 22 14
Insulation stripping length for the cores 5 mm
Screw tightening torque 0.5 Nm
Technical specifications, screw terminals
Cross-section of rigid cores 0.14 mm² 1.5 mm²
Cross-section of flexible cores
31)
0.14 mm² 1.0 mm²
American Wire Gauge (AWG) 26 16
Insulation stripping length for the cores 5 mm
Screw tightening torque 0.22 Nm 0.3 Nm
Cable length for power supply tolerance ±10%
For wire cross-section 1 mm² 50 m
For wire cross-section 0.5 mm² 25 m
For wire cross-section 0.25 mm² 12 m
Cable length for power supply tolerance ±5%
For wire cross-section 1 mm² 60 m
For wire cross-section 0.5 mm² 30 m
For wire cross-section 0.25 mm² 15 m
25)
Operation only in a short-circuit protected system with max. 8 A.
26)
To meet the requirements of the relevant product standards (e.g. IEC 61496<1), the external voltage supply
for the devices (SELV) must be able to bridge a brief mains failure of 20 ms. Power supplies according to EN
60204<1 satisfy this requirement. Suitable power supplies are available as accessories from SICK.
27)
The absolute voltage level must not drop below the specified minimum voltage.
28)
The load currents for the input capacitors are not taken into account.
29)
With a typical supply voltage of 24 V.
30)
Core terminating sleeves are not required.
31)
Core terminating sleeves are not required.
