SICK S300 User Manual

Operating instructions Chapter 4
S300
8010948/YY96/2016-02-17 © SICK AG • Industrial Safety Systems • Germany • All rights reserved 31
Subject to change without notice
Configurable functions
Interoperability in an EFI system depending on the firmware version
Firmware S300 Standard S300 Standard S300 Advanced S300 Advanced S300 Professional S300 Professional S300 Professional CMS S300 Expert S300 Expert S300 Expert CMS
Firmware
M02.10
<02.10
M02.10
<02.10
M02.10
<02.10
<02.10
6)
M02.10
<02.10
<02.10
6)
S300 Standard M02.10 X – X  X   X  
S300 Advanced M 02.10 X – X  X   X  
S300 Professional M02.10 X – X  X   X  
S300 Expert M02.10 X – X  X   X  
Tab. 7: Required compatibility mode with different firmware versions of the S300 in an EFI system with other S300
 = Compatibility mode required
X = Compatibility mode not required
5)
– = EFI system not possible
Firmware S3000 Standard S3000 Standard S3000 Advanced S3000 Advanced S3000 Professional S3000 Professional S3000 Professional CMS S3000 Expert S3000 Remote S3000 Remote
Firmware
MB02.41
ZB02.35
MB02.41
ZB02.35
MB02.41
ZB02.35
ZB02.35
6)
MB02.41
MB02.41
ZB02.35
S300 Standard M02.10 X  X  X   X X 
S300 Advanced M 02.10 X  X  X   X X 
S300 Professional M02.10 X  X  X   X X 
S300 Expert M02.10 X  X  X   X X 
Tab. 8: Required compatibility mode with different firmware versions of the S300 in an EFI system with other safety laser scanners
 = Compatibility mode required
X = Compatibility mode not required
7)
The S300 Mini does not support the compatibility mode. For EFI systems with the S300
Mini safety laser scanner, a device must be used that is not operated in the compatibility
mode.
5)
Make sure that the serial number of the system plug on both devices is > 12210000.
6)
This variant supports exclusively the compatibility mode.
7)
Make sure that the serial number of the S300 system plug is > 12210000 and that the S3000 I/O module is
current (S3000 Standard, Advanced, Professional with I/O module with serial number > 12210000, S3000
Remote with I/O module with serial number > 11240000).
Note

SICK S300 Specifications

General

Protection Class	IP65
Resolution	30 mm
Interface	RS-422, Ethernet
Power Supply	24 V DC
Operating Temperature	0 °C ... +50 °C
