Application examples and
connection diagrams
The two areas to be monitored are switched using the static control inputs depending on
the process phase. For example the area  or the area  can be monitored, both areas
can be monitored or none. For safety against manipulation on the S3000, e.g. the floor is
used as a reference in each case. If the alignment of the S3000 changes (e.g. due to
change to the mounting), the S3000 shuts down.
7.2 Mobile applications
7.2.1 Vehicle monitoring for unidirectional travel (S3000 Standard)
The S3000 monitors the area in one direction of travel and stops the vehicle as soon as
there is an object in the protective field.
Fig.
68
:
Access protection
with S3000 Advanced
Fig.
69
:
Vehicle monitoring
with S3000 Standard


S3000
Advanced with two
protective fields – mounted
vertically
Floor as reference
S3000 Standard with
one protective field
and warning field
