SICK S3000 User Manual

Chapter 4 Operating instructions
S3000
38 © SICK AG • Industrial Safety Systems • Germany • All rights reserved 8009942/WK81/2012-11-28
Subject to change without notice
Configurable functions
4.3.1 Resolution
The maximum protective field range
18)
depends on the configured resolution and the
angular resolution. The following table shows the configurable values:
Maximum protective field range
Short Range sensor head
At 0.5° angular resolution
(60 ms basic response time)
At 0.25° angular resolution
(120 ms basic response time)
30 mm (hand detection) 1.90 m 2.80 m
40 mm (hand detection) 2.60 m 3.80 m
50 mm (leg detection) 3.30 m 4.00 m
70 mm (leg detection) 4.00 m 4.00 m
150 mm (body detection)
1
9)
4.00 m 4.00 m
Medium Range sensor head
30 mm (hand detection) 1.90 m 2.80 m
40 mm (hand detection) 2.60 m 3.80 m
50 mm (leg detection) 3.30 m 4.80 m
70 mm (leg detection) 4.70 m 5.50 m
150 mm (body detection)
19)
5.50 m 5.50 m
Long Range sensor head
30 mm (hand detection) 1.90 m 2.80 m
40 mm (hand detection) 2.60 m 3.80 m
50 mm (leg detection) 3.30 m 4.80 m
70 mm (leg detection) 4.70 m 7.00 m
150 mm (body detection)
19)
7.00 m 7.00 m
The warning field can be configured to up to 49 m for all variants and resolutions. The
detection capability within the warning field is dependent on the remission of the objects
to be detected (see section 12.1 “Characteristics” on page 142).
4.3.2 Basic response time
The basic response time is dependent on the selected angular resolution. It is:
 60 ms basic response time at 0.5° angular resolution
 120 ms basic response time at 0.25° angular resolution
You may need to add supplements to the basic response time due to multiple sampling
and data transmission over EFI (see section 12.2 “OSSD response times” on page 144).
18)
Radial distance to the safety laser scanner.
19)
Cannot be configured for mobile applications.
Tab.
10
:
Maximum protective
field ranges
Note
Note
