SICK S3000 User Manual

Chapter 12 Operating instructions
S3000
144 © SICK AG • Industrial Safety Systems • Germany • All rights reserved 8009942/WK81/2012-11-28
Subject to change without notice
Technical specifications
12.2 OSSD response times
The total response time of your application is dependent on …
 the basic response time at the related resolution and the maximum protective field
range.
 the multiple sampling set.
 the OSSDs used.
How to calculate the total response time T
S
:
T
S
=t
B
+ T
MFA
+ T
EFI
Where …
t
B
= Basic response time (60 ms or 120 ms)
T
M
FA
= Supplement due to multiple sampling > 2
T
E
FI
= Supplement for the usage of external OSSDs via EFI
Multiple sampling
On the S3000 at least double multiple sampling is always set. From a multiple sampling of
3 you must add a supplement to the response time. The related supplement is dependent
on the basic response time and the multiple sampling.
Multiple sampling
Supplement for basic
response time 60 ms
Supplement for basic
response time 120 ms
3 times 30 ms 60 ms
4 times 60 ms 120 ms
5 times 90 ms 180 ms
6 times 120 ms 240 ms
7 times 150 ms 300 ms
8 times 180 ms 360 ms
9 times 210 ms 420 ms
10 times 240 ms 480 ms
11 times 270 ms 540 ms
12 times 300 ms 600 ms
13 times 330 ms 660 ms
14 times 360 ms 720 ms
15 times 390 ms 780 ms
16 times 420 ms 840 ms
External OSSDs
If you use the OSSDs on another device via EFI as external output signal switching devices
(for example with two S3000 connected together), the response time increases by 20 ms
in each case.
Tab.
40
:
Supplements for
multiple sampling
Note
