SICK S3000

Operating instructions Chapter 13
S3000
8009942/WK81/2012-11-28 © SICK AG • Industrial Safety Systems • Germany • All rights reserved 165
Subject to change without notice
Ordering information
13.3.5 Service cables
Part Description Part number
Service cable 2 m For connecting the configuration connection to
the serial interface on the PC
M8× 4 pin/D<Sub 9 pin, approx. 2 m
6021195
Service cable 10 m For connecting the configuration connection to
the serial interface on the PC
M8× 4 pin/D<Sub 9 pin, approx. 10 m
2027649
USB service cable
2 m
For connecting the configuration connection to
the USB interface on the PC
M8× 4-pin/USB-A plug, approx. 2 m
6034574
USB service cable
10 m
For connecting the configuration connection to
the USB interface on the PC
M8× 4-pin/USB-A plug, approx. 10 m
6034575
USB/RS-232
adapter
USB-A plug to D-Sub socket, 9-pin 6035396
13.3.6 Self assembly connecting cables
Part Part number
9 cores, cross-section 0.56 mm² (AWG 20), by the meter 6022651
13 cores, cross-section 0.56 mm² (AWG 20), by the meter 6025729
17 cores, cross-section 0.56 mm² (AWG 20), by the meter 6025730
EFI cable, per meter (1 × 2 × 0.22 mm²) 6029448
DeviceNet connecting cable, PVC, cable diameter 12.2 mm, by the
meter
6030756
DeviceNet connecting cable, PVC, cable diameter 6.9 mm, by the meter 6030921
Interconnectron plug, can be used for DeviceNet connecting cable
6.9 mm (6030921).
6024742
M12 EMC-proof cable gland for EFI connections and incremental
encoders, permissible cable diameter 3-6.5 mm, height 19 mm
5308757
M12 EMC-proof cable gland for EFI connections and incremental
encoders, permissible cable diameter 3-6.5 mm, height 25 mm
5314772
M20 EMC-proof cable gland for supply cables and signal cables,
permissible cable diameter 7-12 mm, height 23 mm
5308762
M20 EMC-proof cable gland for supply cables and signal cables,
permissible cable diameter 10-14 mm, height 23 mm
5318531
M20 EMC-proof cable gland for supply cables and signal cables,
permissible cable diameter 6-12 mm, height 32.5 mm
5323688
M20 EMC-proof cable gland for supply cables and signal cables,
permissible cable diameter 10-14 mm, height 33 mm
5314774
13.3.7 Documentation
Part Part number
CDS (Configuration & Diagnostic Software) on CD-ROM including online
documentation and operating instructions in all available languages
2032314
Tab.
49
:
Part numbers
service cables
Tab.
50
:
Part numbers
connecting cables
Tab.
51
:
Part numbers,
documentation
