Operating instructions Chapter 4
S3000
8009942/WK81/2012-11-28 © SICK AG • Industrial Safety Systems • Germany • All rights reserved 37
Subject to change without notice
Configurable functions
4.3 Application
W
ith the help of the CDS you can configure the S3000 for the required application.
Depending on whether you select a stationary or a mobile application, different
configuration options are available:
Mobile applications Stationary applications
Resolution
 30 mm (hand detection with smaller
protective field size)
 40 mm (hand detection with larger
protective field size)
 50 mm (leg detection with smaller
protective field size)
 70 mm (leg detection with larger
protective field size)
17)
 30 mm (hand detection with smaller
protective field size)
 40 mm (hand detection with larger
protective field size)
 50 mm (leg detection with smaller
protective field size)
 70 mm (leg detection with larger
protective field size)
 150 mm (body detection)
Manipulation prevention
The safety laser scanner checks whether in any 90° segment all measured values
correspond to the maximum distance value that can be measured.
 If this is the case, the S3000 shuts down
after 2 hours and signals .
 If this the case, the S3000 shuts down
after 5 seconds and signals .
17)
In mobile applications a resolution of only 70 mm is required for leg detection, as a coarser resolution is
adequate for the detection of a human leg due to the movement of the vehicle.

Tab.
9
:
Comparison of mobile
and stationary applications
