12.5 EFI status information and control commands
I
f devices are connected together via EFI, EFI status information and control commands
are exchanged. Tab. 42 and Tab. 43 shows the status information that can be retrieved
and the possible control commands for the S3000.
 The information in square brackets reflects the names used in the CDS and in the
Flexi Soft Designer.
 If the devices are operated in the compatibility mode, then restricted EFI status
information and control commands are available.
Status information Meaning/effect
OSSD on [OSSD]  Logical 1, if the internal OSSD of the S3000 is
in the ON state (green)
 Logical 0, if the OSSD of the S3000 is in the
OFF state (red)
Warning field bit [WF LED]
 Logical 1, if warning field 1 and warning field 2
of the S3000 are free or not used
Contamination [Weak]  Logical 1, if the front screen is contaminated
Reset required [Res. Req]  Logical 1, if reset required
Reset button pressed [Res. Pressed]
 Logical 1, if the reset button is pressed on the
S3000
I/O error [I/O Error]  Logical 0, if there is no error on the S3000
 Logical 1, if there is an error on the S3000
Control input A1 [In A1]  Logical 1, if the connection of control input A1
is HIGH
4
5)
Control input A2 [In A2]  Logical 1, if the connection of control input A2
is HIGH
45)
Control input B1 [In B1]  Logical 1, if the connection of control input B1
is HIGH
45)
Control input B2 [In B2]  Logical 1, if the connection of control input B2
is HIGH
45)
Control input C1 [In C1]  Logical 1, if the connection of control input C1
is HIGH
45)
Control input C2 [In C2]  Logical 1, if the connection of control input C2
is HIGH
45)
Control input D1 [In D1]  Logical 1, if the connection of control input D1
is HIGH
45)
Control input D2 [In D2]  Logical 1, if the connection of control input D2
is HIGH
45)
45)
Only if the inputs are activated in the CDS.
Notes
Tab.
42
:
Status information
of the S3000 (data from the
S3000)
