SICK S3000 User Manual

Chapter 12 Operating instructions
S3000
158 © SICK AG • Industrial Safety Systems • Germany • All rights reserved 8009942/WK81/2012-11-28
Subject to change without notice
Technical specifications
Control feature Meaning/effect
Static input information A1 [In A1]  Logical 1, stimulates control input A1 of the
S3000
Static input information A2 [In A2]  Logical 1, stimulates control input A2 of the
S3000
Static input information B1 [In B1]  Logical 1, stimulates control input B1 of the
S3000
Static input information B2 [In B2]  Logical 1, stimulates control input B2 of the
S3000
Static input information C1 [In C1]  Logical 1, stimulates control input C1 of the
S3000
Static input information C2 [In C2]  Logical 1, stimulates control input C2 of the
S3000
Static input information D1 [In D1]  Logical 1, stimulates control input D1 of the
S3000
Static input information D2 [In D2]  Logical 1, stimulates control input D2 of the
S3000
Static input information E1 [In E1]
4
7)
 Logical 1, stimulates control input E1 of the
S3000
Static input information E2 [In E2]
4
7)
 Logical 1, stimulates control input E2 of the
S3000
Stand<by
47)
 Logical 1, stimulates operational status
Stand<by (individually for host and guest)
Speed valid
47)
 Logical 1, valid velocity is present on the
incremental encoder inputs
 Logical 0, invalid velocity is present on the
incremental encoder inputs
Speed
47)
 12 bits for the transmission of the velocity
100000110000 = –2000 cm/s
000000000000 = 0 cm/s
011111010000 = +2000 cm/s
I/O error [I/O Error]  Logical 0, if there is no error on the connected
partner device
 Logical 1, if there is an error on the connected
partner device
47)
Not in the compatibility mode.
Tab.
43
:
Control features on
the S3000 (data to the
S3000)
