Operating instructions Chapter 12
S3000
8009942/WK81/2012-11-28 © SICK AG • Industrial Safety Systems • Germany • All rights reserved 161
Subject to change without notice
Technical specifications
12.6.3 Scan plane origin
Fig.
103
:
Dimensional
drawing of the scan plane
(mm)
Fig.
104
:
Dimensional
drawing of the scan plane
with mounting kit 3 (mm)
102
63
