Technical specifications
12.1.2 Reset pulse
If the reset pulse on the “Reset” input is, e.g., provided by an (F)PLC, then the pulse must
be of a specific length.
Ensure that pulses do not have a frequency of 1 Hz or 4 Hz, as otherwise there may be
overlaps with the application diagnostic output signals for “Front screen contaminated” or
“System error”. This overlap will result in an error on the safety laser scanner.
Fig.
94
:
Diagram scanning
range with Long Range
sensor head
Fig.
95
:
Reset pulse
requirements
t
[ms]
N
500
ms
10
20
24
V
[S]
0
White plaster
Remission [%]
Scanning range [m]
Black shoe leather
0.1
1
2
10
0.2
0.5
1
2
5
10
20
50
5
20
50
100
200
500
Mat black paint
Gray cardboard
Writing paper
Reflectors >2000  %
Reflective films >300
 %
Protective field
Warning field
