Operating instructions Chapter 3
S3000
8009942/WK81/2012-11-28 © SICK AG • Industrial Safety Systems • Germany • All rights reserved 23
Subject to change without notice
Product description
3.3.2 Functions of the I/O modules
Functions Standard Advanced Professional Expert Remote
3)
Object resolution [mm] 30/40/50/70/150
Pairs of output signal switching devices (OSSDs) 11111
External device monitoring (EDM) 
Universal I/Os 33333
Restart interlock/delay 
Field sets consisting of protective field and
warning field (dual field mode) or of two
protective fields (dual protective field mode)
2
4)
4 8 32 32
5)
Can be used for the simultaneous monitoring of
two areas. The areas can each be monitored with
one protective field and one warning field (dual
field mode) or with two protective fields (dual
protective field mode).
6)
In this way it is possible
to monitor up to four protective fields
7).

Field sets consisting of one protective field and
two warning fields (triple field mode) with an
angular resolution of 0.5°
1 4 8 21 21
8)
Field sets consisting of one protective field and
two warning fields (triple field mode) with an
angular resolution of 0.25°
1 4 8 10 10
Programmable monitoring cases in standalone
mode
1 43232–
Programmable monitoring cases in an EFI system 32 32 32 32 32
Static control inputs for monitoring case switching – 2 2 2 –
Static/dynamic control inputs for monitoring case
switching
––22–
EFI interface (safe SICK device communication) 
Output of the measured data (surrounding
contour)

Extended CMS functions (reflector detection, filter
function for the measured values)
––– –
3)
Valid for I/O modules with serial number > 11240000.
4)
The second field set on the S3000 Standard can only be used as a simultaneous field set.
5)
Maximum possible number of field sets — the actual number is the same as for the S3000 variant to which an
S3000 Remote is connected.
6)
Function is available from firmware B02.43.
7)
If two or four protective fields are monitored, then the cut-off paths must be routed to independent OSSD
pairs with the aid of a Flexi Soft safety controller.
8)
Only in combination with S3000 Expert or in standalone operation with Flexi Soft safety controller.
Tab.
2
:
Functions of the
I/O modules
