Technical specifications
Status information Meaning/effect
Allocated protective field
unoccupied [PF]
In dual field mode, in dual protective field mode
a
nd in triple field mode: Logical 1, if the active
allocated protective field is unoccupied
Allocated warning field
u
noccupied [WF]
or
allocated protective field 2
unoccupied [PF2]
In dual field mode: Logical 1, if the active
a
llocated warning field is unoccupied
In dual protective field mode: Logical 1, if the
active allocated protective field 2 is unoccupied
In triple field mode: Logical 1, if the active
allocated warning field is unoccupied
Simultaneous protective field
unoccupied [Sim. PF]
In dual field mode and in dual protective field
mode: Logical 1, if the simultaneously
monitored protective field is unoccupied
In triple field mode: no function
Simultaneous warning field
unoccupied [Sim. WF]
or
simultaneous protective field 2
unoccupied [Sim. PF2]
or
allocated warning field 2
unoccupied [WF2]
In dual field mode: Logical 1, if the
simultaneously monitored warning field is
unoccupied
In dual protective field mode: Logical 1, if the
simultaneously monitored protective field 2 is
unoccupied
In triple field mode: Logical 1, if the active
allocated warning field 2 is unoccupied
Speed valid
46)
Logical 1, if a valid velocity is present on the
incremental encoder inputs
Logical 0, if an invalid velocity is present on the
incremental encoder inputs
Speed
46)
12 bits for the transmission of the velocity
100000110000 = –2000 cm/s
000000000000 = 0 cm/s
011111010000 = +2000 cm/s
46)
Not in the compatibility mode.
