Configurable functions
1-of-n sampling
With 1-of-n sampling you use the single connections of the control input pairs.
A1 A2 B1 B2 Result (e.g. monitoring case no.)
1000 1
0100 2
0010 3
0001 4
0
000 Error
1100 Error
 All connections must be connected.
 Only one connection is ever allowed to be 1.
Tab.
13
:
Truth table for
1>of>n sampling with two
input pairs
