Operating instructions Chapter 4
S3000
8009942/WK81/2012-11-28 © SICK AG • Industrial Safety Systems • Germany • All rights reserved 53
Subject to change without notice
Configurable functions
If the protective field  or the warning fields  stretch as far as a wall or another object
(pillar, neighboring machine, shelf), there should be a distance of 100 mm between the
protective field or warning field and the object  to prevent false triggering.
WARNING
Secure unprotected areas!
If it is possible to access a narrow strip between the protective field and a wall or another
object, you must protect this strip using additional measures (e.g. fence or floor
protection).
Note
Fig.
22
:
Configuring
protective field and warning
field
