Operating instructions Chapter 4
S3000
8009942/WK81/2012-11-28 © SICK AG • Industrial Safety Systems • Germany • All rights reserved 59
Subject to change without notice
Configurable functions
Static 1-of-n sampling
With 1-of-n sampling you use the single connections of the control input pairs. In this way
t
he S3000 Advanced provides four and the S3000 Professional/Expert eight input
connections.
 Using external inputs (e.g. those of a Flexi Soft safety controller, see section 4.5 “Inputs”
on page 43) maximally ten input connections can be used.
 All connections must be connected!
 One connection must be 1!
 Only one connection is ever allowed to be 1!
A1 A2 B1 B2 C1 C2 D1 D2 E1 E2 E.g. case
1000000000 1
0100000000 2
0010000000 3
0001000000 4
0000100000 5
0000010000 6
0000001000 7
0000000100 8
0000000010 9
0000000001 10
1100000000Error
0001100000Error
0000000000Error
And all other combinations Error
Notes
Tab.
18
:
Truth table for
1>of>n sampling
