Addr. Parameter C Setting Options Default Setting Comments
1920 51Nc-1 Rec. Cu. NO
Curve A (101)
Curve B (117)
Curve C (133)
Curve D (116)
Curve E (132)
Curve K (162)
Curve N (104)
Curve R (105)
Curve W (138)
Curve 2 (135)
Curve 3 (140)
Curve 8 (113)
Curve 8* (111)
Curve 9 (131)
Curve 11 (141)
NO 51Nc-1 Recloser Curve
1921 51Nc-1 MinO.T 0.00 .. 30.00 sec 0.01 sec Min Operating Time
51Nc-1
1925A 51Nc Time adder 0.00 .. 30.00 sec 0.00 sec Constant time adder 51Nc
2001 67c-2 PICKUP 1A 0.10 .. 30.00 A; ∞ 10.00 A 67c-2 Pickup
5A 0.50 .. 150.00 A; ∞ 50.00 A
2002 67c-2 DELAY 0.00 .. 60.00 sec; ∞ 0.00 sec 67c-2 Time Delay
2003 67c-1 PICKUP 1A 0.10 .. 30.00 A; ∞ 2.00 A 67c-1 Pickup
5A 0.50 .. 150.00 A; ∞ 10.00 A
2004 67c-1 DELAY 0.00 .. 60.00 sec; ∞ 0.30 sec 67c-1 Time Delay
2005 67c-TOC PICKUP 1A 0.10 .. 4.00 A 1.50 A 67c Pickup
5A 0.50 .. 20.00 A 7.50 A
2006 67c-TOC T-DIAL 0.05 .. 3.20 sec; ∞ 0.50 sec 67c Time Dial
2006 67c-TOC T-DIAL 0.01 .. 20.00 sec; ∞ 0.50 sec 67c Time Dial
2007 67c-TOC T-DIAL 0.50 .. 15.00 ; ∞ 5.00 67c Time Dial
2008 67c-3 PICKUP 1A 1.00 .. 30.00 A; ∞ ∞ A 67c-3 Pickup
5A 5.00 .. 150.00 A; ∞ ∞ A
2009 67c-3 DELAY 0.00 .. 60.00 sec; ∞ 0.00 sec 67c-3 Time Delay
2010 67c-TOC D.out Disk Emulation
Instantaneous
Disk Emulation Drop-out Characteristic
2011 67c-TOC IEC Normal Inverse
Very Inverse
Extremely Inv.
Long Inverse
Normal Inverse IEC Curve
2012 67c-TOC ANSI Very Inverse
Inverse
Short Inverse
Long Inverse
Moderately Inv.
Extremely Inv.
Definite Inv.
Very Inverse ANSI Curve
