Addr. Parameter C Setting Options Default Setting Comments
2013 67c-TOC Recl. Curve A (101)
Curve B (117)
Curve C (133)
Curve D (116)
Curve E (132)
Curve K (162)
Curve N (104)
Curve R (105)
Curve W (138)
Curve 2 (135)
Curve 3 (140)
Curve 8 (113)
Curve 8* (111)
Curve 9 (131)
Curve 11 (141)
Curve A (101) Recloser Curve
2014 67c-TOC-1 PU 1A 0.10 .. 4.00 A; ∞ 1.00 A 67c-TOC-1 Pickup
5A 0.50 .. 20.00 A; ∞ 5.00 A
2015 67c-TOC-1 TD 0.01 .. 20.00 sec; ∞ 0.50 sec 67c-TOC-1 Time Dial
2016 67c-TOC-1 D.o. Instantaneous
Disk Emulation
Disk Emulation Drop-out Characteristic
2017 67c-TOC-1 IEC NO
Normal Inverse
Very Inverse
Extremely Inv.
Long Inverse
Normal Inverse 67c-TOC-1 IEC Curve
2018 67c-TOC-1 T ad. 0.00 .. 30.00 sec 0.00 sec Constant time adder 67c-
TOC-1
2019 67c-TOC-1 ANSI NO
Very Inverse
Inverse
Short Inverse
Long Inverse
Moderately Inv.
Extremely Inv.
Definite Inv.
NO 67c-TOC-1 ANSI Curve
Functions
2.4 Dynamic Cold Load Pickup
