Addr. Parameter Setting Options Default Setting Comments
7268 67-TOC Recl 2.C Curve A (101)
Curve B (117)
Curve C (133)
Curve D (116)
Curve E (132)
Curve K (162)
Curve N (104)
Curve R (105)
Curve W (138)
Curve 2 (135)
Curve 3 (140)
Curve 8 (113)
Curve 8* (111)
Curve 9 (131)
Curve 11 (141)
Curve A (101) 67-TOC Recloser Curve before
2.cycle
7269 67N-T IEC 2.C Normal Inverse
Very Inverse
Extremely Inv.
Long Inverse
Normal Inverse 67N-TOC IEC Curve before 2.cycle
7270 67N-T ANSI 2.C Very Inverse
Inverse
Short Inverse
Long Inverse
Moderately Inv.
Extremely Inv.
Definite Inv.
Very Inverse 67N-TOC ANSI Curve before
2.cycle
7271 67N-T Recl. 2.C Curve A (101)
Curve B (117)
Curve C (133)
Curve D (116)
Curve E (132)
Curve K (162)
Curve N (104)
Curve R (105)
Curve W (138)
Curve 2 (135)
Curve 3 (140)
Curve 8 (113)
Curve 8* (111)
Curve 9 (131)
Curve 11 (141)
Curve A (101) 67N-TOC Recloser Curve before
2.cycle
7272 51 ANSI 2.C Very Inverse
Inverse
Short Inverse
Long Inverse
Moderately Inv.
Extremely Inv.
Definite Inv.
Very Inverse 51 ANSI Curve before 2.cycle
