Special Parameters in
Easy Setting GUI View
C Setting Options Default Setting Description
Number Close Opera-
tions to Lockout Phase
0 .. 9 1 This setting will determine
how many close opera-
tions will be executed by
the auto reclose function
before lockout is activated
for phase faults cleared
prior to each close
attempt.
Number Close Opera-
tions to Lockout Gnd.
0 .. 9 1 This setting will determine
how many close opera-
tions will be executed by
the auto reclose function
before lockout is activated
for ground faults cleared
prior to each close
attempt.
Trip #1 Phase Curve Fast Curve x Fast Curve x Select a fast or delayed
curve for the 1st phase
overcurrent trip.
Delayed Curve x
Fast Curve y
Delayed Curve y
Trip #1 Ground Curve Fast Curve x Fast Curve x Select a fast or delayed
curve for the 1st
ground overcurrent
trip.
Delayed Curve x
Fast Curve y
Delayed Curve y
Phase Reclose Interval
1
0.01 .. 320.00 sec 0.50 sec This setting will determine
the reclose interval time in
the 1st phase
reclose cycle.
Ground Reclose
Interval 1
0.01 .. 320.00 sec 0.50 sec This setting will determine
the reclose interval time in
the 1st ground
reclose cycle.
Trip #2 Phase Curve Fast Curve x Fast Curve x Select a fast or delayed
curve for the 2nd phase
overcurrent trip.
Delayed Curve x
Fast Curve y
Delayed Curve y
Trip #2 Ground Curve Fast Curve x Fast Curve x Select a fast or delayed
curve for the 2nd
ground overcurrent
trip.
Delayed Curve x
Fast Curve y
Delayed Curve y
Phase Reclose Interval
2
0.01 .. 320.00 sec 0.50 sec This setting will determine
the reclose interval time in
the 2nd phase
reclose cycle.
Ground Reclose
Interval 2
0.01 .. 320.00 sec 0.50 sec This setting will determine
the reclose interval time in
the 2nd ground
reclose cycle.
Functions
2.29 Recloser Setting Summary
