Siemens 7SC80 - Page 406

Special Parameters in
Easy Setting GUI View
C Setting Options Default Setting Description
Trip #3 Phase Curve Fast Curve x Fast Curve x Select a fast or delayed
curve for the 3rd phase
overcurrent trip.
Delayed Curve x
Fast Curve y
Delayed Curve y
Trip #3 Ground Curve Fast Curve x Fast Curve x Select a fast or delayed
curve for the 3rd
ground overcurrent
trip.
Delayed Curve x
Fast Curve y
Delayed Curve y
Phase Reclose Interval
3
0.01 .. 320.00 sec 0.50 sec This setting will determine
the reclose interval time in
the 3rd phase
reclose cycle.
Ground Reclose
Interval 3
0.01 .. 320.00 sec 0.50 sec This setting will determine
the reclose interval time in
the 3rd ground
reclose cycle.
Trip #4 Phase Curve Fast Curve x Fast Curve x Select a fast or delayed
curve for the 4th phase
overcurrent trip.
Delayed Curve x
Fast Curve y
Delayed Curve y
Trip #4 Ground Curve Fast Curve x Fast Curve x Select a fast or delayed
curve for the 4th
ground overcurrent
trip.
Delayed Curve x
Fast Curve y
Delayed Curve y
Phase Reclose Interval
4
0.01 .. 320.00 sec 0.50 sec This setting will determine
the reclose interval
time in the 4th phase
reclose cycle.
Ground Reclose
Interval 4
0.01 .. 320.00 sec 0.50 sec This setting will determine
the reclose interval time in
the 4th ground
reclose cycle.
Reclose Reset Time 0.50 .. 320.00 sec 3.00 sec This setting will determine
the elapsed time after a
successful reclosing
attempt.If no new trip
provokes when the time
expires, the automatic
reclosure would be reset.
Functions
2.29 Recloser Setting Summary
406 SIPROTEC Compact, 7SC80, Manual
E50417-G1140-C486-A8, Edition 07.2017
