Siemens 7SC80 - Page 407

Special Parameters in
Easy Setting GUI View
C Setting Options Default Setting Description
Close Wait Time 0.10 .. 320.00 sec 3.00 sec
•
If the circuit breaker
turns to not ready,
set the Close Wait
Time to define the
max-allowed time for
the circuit breaker to
recover to normal.
•
If the circuit breaker
is not ready when the
time expires, the
reclosing would be
omitted, the auto-
matic reclosure
would be dynami-
cally blocked.
Only if Circuit Breaker
Check before AR is acti-
vated, the Close Wait
Time parameter is valid.
Minimum Trip Fast
Curve x Phase
1 A 0.10 .. 4.00 A; ∞ 1.00 A Set the minimum trip
values for the Fast
curve x phase.
5 A 0.50 .. 20.00 A; ∞ 5.00 A
Minimum Trip Fast
Curve x Ground
1 A 0.05 .. 4.00 A; ∞ 0.20 A Set the minimum trip
values for the Fast
curve x ground.
5 A 0.25 .. 20.00 A; ∞ 1.00 A
Functions
2.29 Recloser Setting Summary
SIPROTEC Compact, 7SC80, Manual 407
E50417-G1140-C486-A8, Edition 07.2017
