Special Parameters in
Easy Setting GUI View
C Setting Options Default Setting Description
Fast Curve x Phase IEC Curve - Normal Inverse IEC Curve -
Normal Inverse
Set the trip curve type for
the Fast curve x
phase.
IEC Curve - Very Inverse
IEC Curve - Extremely Inverse
IEC Curve - Long Inverse
ANSI Curve - Inverse
ANSI Curve - Short Inverse
ANSI Curve - Long Inverse
ANSI Curve - Moderately Inverse
ANSI Curve - Very Inverse
ANSI Curve - Extremely Inverse
ANSI Curve - Definite Inverse
Recloser Curve - Curve A (101)
Recloser Curve - Curve B (117)
Recloser Curve - Curve C (133)
Recloser Curve - Curve D (116)
Recloser Curve - Curve E (132)
Recloser Curve - Curve K (162)
Recloser Curve - Curve N (104)
Recloser Curve - Curve R (105)
Recloser Curve - Curve W (138)
Recloser Curve - Curve 2 (135)
Recloser Curve - Curve 3 (140)
Recloser Curve - Curve 8 (113)
Recloser Curve - Curve 8* (111)
Recloser Curve - Curve 9 (131)
Recloser Curve - Curve 11 (141)
Functions
2.29 Recloser Setting Summary
408 SIPROTEC Compact, 7SC80, Manual
E50417-G1140-C486-A8, Edition 07.2017
