Special Parameters in
Easy Setting GUI View
C Setting Options Default Setting Description
Fast Curve x Ground IEC Curve - Normal Inverse IEC Curve -
Normal Inverse
Set the trip curve type for
the Fast curve x
ground.
IEC Curve - Very Inverse
IEC Curve - Extremely Inverse
IEC Curve - Long Inverse
ANSI Curve - Inverse
ANSI Curve - Short Inverse
ANSI Curve - Long Inverse
ANSI Curve - Moderately Inverse
ANSI Curve - Very Inverse
ANSI Curve - Extremely Inverse
ANSI Curve - Definite Inverse
Recloser Curve - Curve A (101)
Recloser Curve - Curve B (117)
Recloser Curve - Curve C (133)
Recloser Curve - Curve D (116)
Recloser Curve - Curve E (132)
Recloser Curve - Curve K (162)
Recloser Curve - Curve N (104)
Recloser Curve - Curve R (105)
Recloser Curve - Curve W (138)
Recloser Curve - Curve 2 (135)
Recloser Curve - Curve 3 (140)
Recloser Curve - Curve 8 (113)
Recloser Curve - Curve 8* (111)
Recloser Curve - Curve 9 (131)
Recloser Curve - Curve 11 (141)
Fast Curve x Phase
Time Dial
0.01 .. 20.00 sec; ∞ 0.50 sec Set the time dial for the
Fast curve x phase.
Fast Curve x Ground
Time Dial
0.01 .. 20.00 sec; ∞ 0.20 sec Set the time dial for the
Fast curve x ground.
Fast Curve x Phase
Reset
Instantaneous Disk Emulation Set the reset characteristic
for the Fast curve x
phase.
Disk Emulation
Fast Curve x Ground
Reset
Instantaneous Disk Emulation Set the reset characteristic
for the Fast curve x
ground.
Disk Emulation
Fast Curve x Phase
Time Adder
0.00 .. 30.00 sec 0.00 sec Set the time adder for the
Fast curve x phase.
Fast Curve x Ground
Time Adder
0.00 .. 30.00 sec 0.00 sec Set the time adder for the
Fast curve x ground.
Fast Curve x Ph
Minimum Operating
Time
0.00 .. 30.00 sec 0.01 sec Set the minimum oper-
ating time for the Fast
curve x phase.
Fast Curve x Gnd
Minimum Operating
Time
0.00 .. 30.00 sec 0.01 sec Set the minimum oper-
ating time for the Fast
curve x ground.
Functions
2.29 Recloser Setting Summary
