Special Parameters in
Easy Setting GUI View
C Setting Options Default Setting Description
CLP Curve x Phase IEC Curve - Normal Inverse IEC Curve -
Normal Inverse
Set the trip curve type for
the CLP curve x
phase.
IEC Curve - Very Inverse
IEC Curve - Extremely Inverse
IEC Curve - Long Inverse
ANSI Curve - Inverse
ANSI Curve - Short Inverse
ANSI Curve - Long Inverse
ANSI Curve - Moderately Inverse
ANSI Curve - Very Inverse
ANSI Curve - Extremely Inverse
ANSI Curve - Definite Inverse
Recloser Curve - Curve A (101)
Recloser Curve - Curve B (117)
Recloser Curve - Curve C (133)
Recloser Curve - Curve D (116)
Recloser Curve - Curve E (132)
Recloser Curve - Curve K (162)
Recloser Curve - Curve N (104)
Recloser Curve - Curve R (105)
Recloser Curve - Curve W (138)
Recloser Curve - Curve 2 (135)
Recloser Curve - Curve 3 (140)
Recloser Curve - Curve 8 (113)
Recloser Curve - Curve 8* (111)
Recloser Curve - Curve 9 (131)
Recloser Curve - Curve 11 (141)
CLP Curve x Phase
Time Dial
0.01 .. 20.00 sec; ∞ 0.50 sec Set the time dial for the
CLP curve x phase.
CLP Curve x Phase
Reset
Instantaneous Disk Emulation Set the reset characteristic
for the CLP curve x
phase.
Disk Emulation
CLP Curve x Phase
Time Adder
0.00 .. 30.00 sec 0.00 sec Set the time adder for the
CLP curve x phase.
CLP Curve x Phase Min
Operating Time
0.00 .. 30.00 sec 0.01 sec Set the minimum oper-
ating time for CLP curve
x phase.
Minimum Trip CLP
Curve x Ground
1 A 0.05 .. 4.00 A; ∞ 0.20 A Set the minimum trip
values for the CLP curve
x ground.
5 A 0.25 .. 20.00 A; ∞ 1.00 A
Functions
