Special Parameters in
Easy Setting GUI View
C Setting Options Default Setting Description
CLP Curve x Ground IEC Curve - Normal Inverse IEC Curve -
Normal Inverse
Set the trip curve type for
the CLP curve x
ground.
IEC Curve - Very Inverse
IEC Curve - Extremely Inverse
IEC Curve - Long Inverse
ANSI Curve - Inverse
ANSI Curve - Short Inverse
ANSI Curve - Long Inverse
ANSI Curve - Moderately Inverse
ANSI Curve - Very Inverse
ANSI Curve - Extremely Inverse
ANSI Curve - Definite Inverse
Recloser Curve - Curve A (101)
Recloser Curve - Curve B (117)
Recloser Curve - Curve C (133)
Recloser Curve - Curve D (116)
Recloser Curve - Curve E (132)
Recloser Curve - Curve K (162)
Recloser Curve - Curve N (104)
Recloser Curve - Curve R (105)
Recloser Curve - Curve W (138)
Recloser Curve - Curve 2 (135)
Recloser Curve - Curve 3 (140)
Recloser Curve - Curve 8 (113)
Recloser Curve - Curve 8* (111)
Recloser Curve - Curve 9 (131)
Recloser Curve - Curve 11 (141)
CLP Curve x Ground
Time Dial
0.01 .. 20.00 sec; ∞ 0.50 sec Set the time dial for the
CLP curve x ground.
CLP Curve x Ground
Reset
Instantaneous Disk Emulation Set the reset characteristic
for the CLP curve x
ground.
Disk Emulation
CLP Curve x Ground
Time Adder
0.00 .. 30.00 sec 0.00 sec Set the time adder for the
CLP curve x ground.
CLP Curve x Ground
Min Operating Time
0.00 .. 30.00 sec 0.01 sec Set the minimum oper-
ating time for the CLP
curve x ground.
Enable Frequency OFF OFF This setting will determine
if frequency protection
would be activated in over
mode or under mode or
deactivated.
ON - overfrequency stage
ON - underfrequency stage
Frequency Pickup 50 Hz 40.00 .. 60.00 Hz 49.50 Hz Set the pickup value of
frequency protection.
60 Hz 50.00 .. 70.00 Hz 59.50 Hz
Frequency Time Delay 0.00 .. 100.00 sec; ∞ 60.00 sec Set the time delay of
frequency protection.
Frequency Volt. Super-
vision Pickup
10 .. 150 V 65 V Set the voltage supervi-
sion pickup of frequency
protection.
Functions
2.29 Recloser Setting Summary
