Addr. Parameter Function C Setting Options Default Setting Comments
7400 Triple/Single Triple Single 3PTrip-3PLO
1PTrip-3PLO
1PTrip-1PLO
3PTrip-3PLO Triple/Single Mode
8001 START Fault Locator Pickup
TRIP
Pickup Start fault locator with
8101 MEASURE. SUPERV Meas-
urem.Superv
OFF
ON
ON Measurement Supervision
8102 BALANCE V-LIMIT Meas-
urem.Superv
10 .. 100 V 50 V Voltage Threshold for
Balance Monitoring
8103 BAL. FACTOR V Meas-
urem.Superv
0.58 .. 0.90 0.75 Balance Factor for
Voltage Monitor
8104 BALANCE I LIMIT Meas-
urem.Superv
1A 0.10 .. 1.00 A 0.50 A Current Threshold for
Balance Monitoring
5A 0.50 .. 5.00 A 2.50 A
8105 BAL. FACTOR I Meas-
urem.Superv
0.10 .. 0.90 0.50 Balance Factor for Current
Monitor
8106 Σ I THRESHOLD Meas-
urem.Superv
1A 0.05 .. 2.00 A; ∞ 0.10 A Summated Current Moni-
toring Threshold
5A 0.25 .. 10.00 A; ∞ 0.50 A
8107 Σ I FACTOR Meas-
urem.Superv
0.00 .. 0.95 0.10 Summated Current Moni-
toring Factor
8109 FAST Σi MONIT Meas-
urem.Superv
OFF
ON
ON Fast Summated Current
Monitoring
8201 FCT 74TC 74TC TripCirc. ON
OFF
ON 74TC TRIP Circuit Supervi-
sion
8202 Alarm Delay 74TC TripCirc. 1 .. 30 sec 2 sec Delay Time for alarm
8301 DMD Interval Demand meter 15 Min., 1 Sub
15 Min., 3 Subs
15 Min.,15 Subs
30 Min., 1 Sub
60 Min., 1 Sub
60 Min.,10 Subs
5 Min., 5 Subs
60 Min., 1 Sub Demand Calculation Inter-
vals
8302 DMD Sync.Time Demand meter On The Hour
15 After Hour
30 After Hour
45 After Hour
On The Hour Demand Synchronization
Time
8311 MinMax cycRESET Min/Max meter NO
YES
YES Automatic Cyclic Reset
Function
8312 MiMa RESET TIME Min/Max meter 0 .. 1439 min 0 min MinMax Reset Timer
8313 MiMa RESETCYCLE Min/Max meter 1 .. 365 Days 7 Days MinMax Reset Cycle
Period
8314 MinMaxRES.START Min/Max meter 1 .. 365 Days 1 Days MinMax Start Reset Cycle
in
8315 MeterResolution Energy Standard
Factor 10
Factor 100
Standard Meter resolution
9501 FCT Sec. Sectionalizer OFF
ON
OFF Sectionalizer Function
9502 Sec. CLP Det. Sectionalizer OFF
ON
OFF Sec. Cold Load Pickup
Detection
Functions, Settings, Information
F.2 Settings
