Addr. Parameter Function C Setting Options Default Setting Comments
9511 Sec. CLP PU Sectionalizer 1A 0.04 .. 5.00 A 0.10 A Sec. Cold Load Pickup
5A 0.20 .. 25.00 A 0.50 A
9512 Sec. CLP PU T Sectionalizer 0.00 .. 360.00 sec 0.10 sec Sec. Cold Load Pickup
Time Delay
9513 Sec. CLP DO Sectionalizer 1A 0.04 .. 5.00 A 0.20 A Sec. Cold Load Drop-out
5A 0.20 .. 25.00 A 1.00 A
9514 Sec. CLP DO T Sectionalizer 0.00 .. 360.00 sec 10.00 sec Sec. Cold Load Drop-out
Time Delay
9521 Open Sec. Cnt. Sectionalizer 1 .. 20 2 Open Sec. Counter
9522 Min. Iph Sectionalizer 1A 0.04 .. 30.00 A; ∞ 2.00 A Minimum Phase Current
5A 0.20 .. 150.00 A; ∞ 10.00 A
9523 Min. Ignd Sectionalizer 1A 0.04 .. 30.00 A; ∞ 0.50 A Minimum Neutral Current
5A 0.20 .. 150.00 A; ∞ 2.50 A
9524 Min. Iph CLP Sectionalizer 1A 0.04 .. 30.00 A; ∞ 4.00 A Minimum Phase During
Cold Load
5A 0.20 .. 150.00 A; ∞ 20.00 A
9525 Min. Ignd CLP Sectionalizer 1A 0.04 .. 30.00 A; ∞ 1.00 A Minimum Neutral During
Cold Load
5A 0.20 .. 150.00 A; ∞ 5.00 A
9526 T. to con. Trip Sectionalizer 0.01 .. 30.00 sec 0.15 sec Time to confirm trip
9527 Time to open Sectionalizer 0.00 .. 360.00 sec 5.00 sec Time to open command
9528 Time to reset Sectionalizer 0.00 .. 360.00 sec 10.00 sec Time to reset after last
increase
Functions, Settings, Information
F.2 Settings
SIPROTEC Compact, 7SC80, Manual 693
E50417-G1140-C486-A8, Edition 07.2017
