Siemens 7SC80 - Page 751

No. Description Function Typ
e of
Info
rma
tion
Log Buffers Configurable in Matrix IEC 60870-5-103
Event Log ON/OFF
Trip (Fault) Log ON/OFF
Ground Fault Log ON/OFF
Marked in Oscill. Record
LED
Binary Input
Function Key
Relay
Chatter Suppression
Type
information number
Data Unit
General Interrogation
31120 67N-TOC-3 InRush picked
up (67N-TOC-3InR.PU)
67 Direct.
O/C
OUT * On
Off
* LED BO
31121 >BLOCK 67N-TOC-4 (>BLK
67N-TOC-4)
67 Direct.
O/C
SP * * * LED BI BO
31122 67N-TOC-4 picked up
(67N-TOC-4 PU)
67 Direct.
O/C
OUT * On
Off
* LED BO
31123 67N-TOC-4 TRIP (67N-
TOC-4 TRIP)
67 Direct.
O/C
OUT * On m LED BO
31124 67N-TOC-4 Time Out
(67N-TOC-4 T. O.)
67 Direct.
O/C
OUT * * * LED BO
31125 67N-TOC-4 is BLOCKED
(67N-TOC-4 BLK)
67 Direct.
O/C
OUT On
Of
f
On
Off
* LED BO
31126 67N-TOC-4 InRush picked
up (67N-TOC-4InR.PU)
67 Direct.
O/C
OUT * On
Off
* LED BO
31159 51-1 curve multi-selection
error (51-1 Curve Err.)
50/51
Overcur.
OUT On
Of
f
* * LED BO
31160 51-2 curve multi-selection
error (51-2 Curve Err.)
50/51
Overcur.
OUT On
Of
f
* * LED BO
31161 51-3 curve multi-selection
error (51-3 Curve Err.)
50/51
Overcur.
OUT On
Of
f
* * LED BO
31162 51-4 curve multi-selection
error (51-4 Curve Err.)
50/51
Overcur.
OUT On
Of
f
* * LED BO
31163 51N-1 curve multi-selec-
tion error (51N-1 Curve
Er.)
50/51
Overcur.
OUT On
Of
f
* * LED BO
31164 51N-2 curve multi-selec-
tion error (51N-2 Curve
Er.)
50/51
Overcur.
OUT On
Of
f
* * LED BO
31165 51N-3 curve multi-selec-
tion error (51N-3 Curve
Er.)
50/51
Overcur.
OUT On
Of
f
* * LED BO
31166 51N-4 curve multi-selec-
tion error (51N-4 Curve
Er.)
50/51
Overcur.
OUT On
Of
f
* * LED BO
31167 67-TOC-1 curve multi-
selection error (67-TOC-1
C. Er.)
67 Direct.
O/C
OUT On
Of
f
* * LED BO
Functions, Settings, Information
F.3 Information List
SIPROTEC Compact, 7SC80, Manual 751
E50417-G1140-C486-A8, Edition 07.2017
