Siemens 7SC80 - Page 752

No. Description Function Typ
e of
Info
rma
tion
Log Buffers Configurable in Matrix IEC 60870-5-103
Event Log ON/OFF
Trip (Fault) Log ON/OFF
Ground Fault Log ON/OFF
Marked in Oscill. Record
LED
Binary Input
Function Key
Relay
Chatter Suppression
Type
information number
Data Unit
General Interrogation
31168 67-TOC-2 curve multi-
selection error (67-TOC-2
C. Er.)
67 Direct.
O/C
OUT On
Of
f
* * LED BO
31169 67-TOC-3 curve multi-
selection error (67-TOC-3
C. Er.)
67 Direct.
O/C
OUT On
Of
f
* * LED BO
31170 67-TOC-4 curve multi-
selection error (67-TOC-4
C. Er.)
67 Direct.
O/C
OUT On
Of
f
* * LED BO
31171 67N-TOC-1 curve multi-
selection error (67N-
TOC-1 C.Er.)
67 Direct.
O/C
OUT On
Of
f
* * LED BO
31172 67N-TOC-2 curve multi-
selection error (67N-
TOC-2 C.Er.)
67 Direct.
O/C
OUT On
Of
f
* * LED BO
31173 67N-TOC-3 curve multi-
selection error (67N-
TOC-3 C.Er.)
67 Direct.
O/C
OUT On
Of
f
* * LED BO
31174 67N-TOC-4 curve multi-
selection error (67N-
TOC-4 C.Er.)
67 Direct.
O/C
OUT On
Of
f
* * LED BO
31175 >BLOCK Sec. Cold Load
Pickup (>BLK. Sec. CLP)
Sectional-
izer
SP On
Of
f
* * LED BI BO
31176 Sec. Cold-Load-Pickup
switched OFF (Sec. CLP
OFF)
Sectional-
izer
OUT On
Of
f
* * LED BO
31177 Sec. Cold-Load-Pickup is
BLOCKED (Sec. CLP BLK.)
Sectional-
izer
OUT On
Of
f
On
Off
* LED BO
31178 Sec. Cold-Load-Pickup is
RUNNING (Sec. CLP run.)
Sectional-
izer
OUT On
Of
f
* * LED BO
31179 Sec. Dynamic Settings are
ACTIVE (Sec. Dyn set.)
Sectional-
izer
OUT On
Of
f
* * LED BO
31180 >BLOCK Sectionalizer
(>BLOCK Sec.)
Sectional-
izer
SP On
Of
f
* * LED BI BO
31181 Sectionalizer switched
OFF (Sec. OFF)
Sectional-
izer
OUT On
Of
f
* * LED BO
Functions, Settings, Information
F.3 Information List
752 SIPROTEC Compact, 7SC80, Manual
E50417-G1140-C486-A8, Edition 07.2017
