No. Description Function Typ
e of
Info
rma
tion
Log Buffers Configurable in Matrix IEC 60870-5-103
Event Log ON/OFF
Trip (Fault) Log ON/OFF
Ground Fault Log ON/OFF
Marked in Oscill. Record
LED
Binary Input
Function Key
Relay
Chatter Suppression
Type
information number
Data Unit
General Interrogation
31182 Sectionalizer is BLOCKED
(Sec. BLOCKED)
Sectional-
izer
OUT On
Of
f
On
Off
* LED BO
31183 Sectionalizer picked up
(Sec. picked up)
Sectional-
izer
OUT * On
Off
* LED BO
31184 Sectionalizer counter
(Sec. counter )
Sectional-
izer
VI On
Of
f
On
Off
31185 Sectionalizer open
command (Sec. open)
Sectional-
izer
OUT * On * LED BO
31186 Sectionalizer is ACTIVE
(Sec. ACTIVE)
Sectional-
izer
OUT On
Of
f
* * LED BO
31188 Primary Sectionalizer fault
current Ia (Sec. Ia =)
Sectional-
izer
VI * On
Off
31189 Primary Sectionalizer fault
current Ib (Sec. Ib =)
Sectional-
izer
VI * On
Off
31190 Primary Sectionalizer fault
current Ic (Sec. Ic =)
Sectional-
izer
VI * On
Off
31191 Primary Sectionalizer fault
current In (Sec. In =)
Sectional-
izer
VI * On
Off
31261 >BLOCK 27 undervolt.
prot. Side2 (>BLOCK 27
S2)
27/59 S2 SP * * * LED BI BO
31262 >27-Switch current
superv. ON Side2 (>27 I
SUP. S2)
27/59 S2 SP On
Of
f
* * LED BI BO
31263 >BLOCK 27-1 Undervolt.
prot. Side2 (>BLOCK 27-1
S2)
27/59 S2 SP On
Of
f
* * LED BI BO
31264 >BLOCK 27-2 Undervolt.
prot. Side2 (>BLOCK 27-2
S2)
27/59 S2 SP On
Of
f
* * LED BI BO
31265 27 Under-
volt.prot.switched OFF
Side2 (27 OFF S2)
27/59 S2 OUT On
Of
f
* * LED BO
31266 27 Undervolt. prot. is
BLOCKED Side2 (27
BLOCKED S2)
27/59 S2 OUT On
Of
f
On
Off
* LED BO
31267 27 Undervolt. prot. is
ACTIVE Side2 (27 ACTIVE
S2)
27/59 S2 OUT On
Of
f
* * LED BO
31268 27-1 Undervolt. picked up
Side2 (27-1 PU S2)
27/59 S2 OUT * On
Off
* LED BO
Functions, Settings, Information
F.3 Information List
