Siemens 7SC80 - Page 754

No. Description Function Typ
e of
Info
rma
tion
Log Buffers Configurable in Matrix IEC 60870-5-103
Event Log ON/OFF
Trip (Fault) Log ON/OFF
Ground Fault Log ON/OFF
Marked in Oscill. Record
LED
Binary Input
Function Key
Relay
Chatter Suppression
Type
information number
Data Unit
General Interrogation
31269 27-1 PICKUP w/curr.
superv Side2 (27-1 PU CS
S2)
27/59 S2 OUT * On
Off
* LED BO
31270 27-2 Undervolt. picked up
Side2 (27-2 PU S2)
27/59 S2 OUT * On
Off
* LED BO
31271 27-2 PICKUP w/curr.
superv Side2 (27-2 PU CS
S2)
27/59 S2 OUT * On
Off
* LED BO
31272 27-1 Undervoltage TRIP
Side2 (27-1 TRIP S2)
27/59 S2 OUT * On * LED BO
31273 27-2 Undervoltage TRIP
Side2 (27-2 TRIP S2)
27/59 S2 OUT * On * LED BO
31274 >BLOCK 59 overvolt. prot.
Side2 (>BLOCK 59 S2)
27/59 S2 SP * * * LED BI BO
31275 59 Over-
volt.prot.switched OFF
Side2 (59 OFF S2)
27/59 S2 OUT On
Of
f
* * LED BO
31276 59 Overvolt.prot.is
BLOCKED Side2 (59
BLOCKED S2)
27/59 S2 OUT On
Of
f
On
Off
* LED BO
31277 59 Overvolt.prot.is
ACTIVE Side2 (59 ACTIVE
S2)
27/59 S2 OUT On
Of
f
* * LED BO
31278 59-1 Overvolt. picked up
Side2 (59-1 PU S2)
27/59 S2 OUT * On
Off
* LED BO
31279 59-1 Overvolt. TRIP Side2
(59-1 TRIP S2)
27/59 S2 OUT * On * LED BO
31280 59-2 Overvolt. picked up
Side2 (59-2 PU S2)
27/59 S2 OUT * On
Off
* LED BO
31281 59-2 Overvolt. TRIP Side2
(59-2 TRIP S2)
27/59 S2 OUT * On * LED BO
31282 >Frq. MIN/MAX Buffer
Reset Side2 (>FrqMiMaR-
esetS2)
Min/Max
meter
SP On * * LED BI BO
31283 27-1 Phase 2A Under-
voltage pickup (27-1
Ph2A PU)
27/59 S2 OUT * On
Off
* LED BO
31284 27-1 Phase 2B Under-
voltage pickup (27-1
Ph2B PU)
27/59 S2 OUT * On
Off
* LED BO
31285 27-1 Phase 2C Under-
voltage pickup (27-1
Ph2C PU)
27/59 S2 OUT * On
Off
* LED BO
Functions, Settings, Information
F.3 Information List
754 SIPROTEC Compact, 7SC80, Manual
E50417-G1140-C486-A8, Edition 07.2017
