No. Description Function Typ
e of
Info
rma
tion
Log Buffers Configurable in Matrix IEC 60870-5-103
Event Log ON/OFF
Trip (Fault) Log ON/OFF
Ground Fault Log ON/OFF
Marked in Oscill. Record
LED
Binary Input
Function Key
Relay
Chatter Suppression
Type
information number
Data Unit
General Interrogation
31286 27-1 Phase 2A PICKUP w/
curr. Supervision (27-1
Ph2A PU CS)
27/59 S2 OUT * On
Off
* LED BO
31287 27-1 Phase 2B PICKUP w/
curr. Supervision (27-1
Ph2B PU CS)
27/59 S2 OUT * On
Off
* LED BO
31288 27-1 Phase 2C PICKUP w/
curr. Supervision (27-1
Ph2C PU CS)
27/59 S2 OUT * On
Off
* LED BO
31289 27-2 Phase 2A Under-
voltage pickup (27-2
Ph2A PU)
27/59 S2 OUT * On
Off
* LED BO
31290 27-2 Phase 2B Under-
voltage pickup (27-2
Ph2B PU)
27/59 S2 OUT * On
Off
* LED BO
31291 27-2 Phase 2C Under-
voltage pickup (27-2
Ph2C PU)
27/59 S2 OUT * On
Off
* LED BO
31292 27-2 Phase 2A PICKUP w/
curr. Supervision (27-2
Ph2A PU CS)
27/59 S2 OUT * On
Off
* LED BO
31293 27-2 Phase 2B PICKUP w/
curr. Supervision (27-2
Ph2B PU CS)
27/59 S2 OUT * On
Off
* LED BO
31294 27-2 Phase 2C PICKUP w/
curr. Supervision (27-2
Ph2C PU CS)
27/59 S2 OUT * On
Off
* LED BO
31295 27-1 Phase 2A Under-
voltage TRIP (27-1 Ph2A
TRIP)
27/59 S2 OUT * On * LED BO
31296 27-1 Phase 2B Under-
voltage TRIP (27-1 Ph2B
TRIP)
27/59 S2 OUT * On * LED BO
31297 27-1 Phase 2C Under-
voltage TRIP (27-1 Ph2C
TRIP)
27/59 S2 OUT * On * LED BO
31298 27-2 Phase 2A Under-
voltage TRIP (27-2 Ph2A
TRIP)
27/59 S2 OUT * On * LED BO
31299 27-2 Phase 2B Under-
voltage TRIP (27-2 Ph2B
TRIP)
27/59 S2 OUT * On * LED BO
