No. Description Function Typ
e of
Info
rma
tion
Log Buffers Configurable in Matrix IEC 60870-5-103
Event Log ON/OFF
Trip (Fault) Log ON/OFF
Ground Fault Log ON/OFF
Marked in Oscill. Record
LED
Binary Input
Function Key
Relay
Chatter Suppression
Type
information number
Data Unit
General Interrogation
31300 27-2 Phase 2C Under-
voltage TRIP (27-2 Ph2C
TRIP)
27/59 S2 OUT * On * LED BO
31301 59-1 Phase 2A picked up
(59-1 Ph2A PU)
27/59 S2 OUT * On
Off
* LED BO
31302 59-1 Phase 2B picked up
(59-1 Ph2B PU)
27/59 S2 OUT * On
Off
* LED BO
31303 59-1 Phase 2C picked up
(59-1 Ph2C PU)
27/59 S2 OUT * On
Off
* LED BO
31304 59-1 Phase 2A TRIP (59-1
Ph 2A TRIP)
27/59 S2 OUT * On * LED BO
31305 59-1 Phase 2B TRIP (59-1
Ph 2B TRIP)
27/59 S2 OUT * On * LED BO
31306 59-1 Phase 2C TRIP (59-1
Ph 2C TRIP)
27/59 S2 OUT * On * LED BO
31307 59-2 Phase 2A picked up
(59-2 Ph2A PU)
27/59 S2 OUT * On
Off
* LED BO
31308 59-2 Phase 2B picked up
(59-2 Ph2B PU)
27/59 S2 OUT * On
Off
* LED BO
31309 59-2 Phase 2C picked up
(59-2 Ph2C PU)
27/59 S2 OUT * On
Off
* LED BO
31310 59-2 Phase 2A TRIP (59-2
Ph 2A TRIP)
27/59 S2 OUT * On * LED BO
31311 59-2 Phase 2B TRIP (59-2
Ph 2B TRIP)
27/59 S2 OUT * On * LED BO
31312 59-2 Phase 2C TRIP (59-2
Ph 2C TRIP)
27/59 S2 OUT * On * LED BO
31313 >V MIN/MAX Buffer Reset
Side2 (>V MiMaReset S2)
Min/Max
meter
SP On * * LED BI BO
31314 >Vphph MIN/MAX Buffer
Reset Side2 (>VphphMi-
MaResS2)
Min/Max
meter
SP On * * LED BI BO
31315 >V1 MIN/MAX Buffer
Reset Side2 (>V1 MiMaR-
esetS2)
Min/Max
meter
SP On * * LED BI BO
31316 >BLOCK 81O/U Side2
(>BLK 81 O/U S2)
81 O/U
Freq.S2
SP On
Of
f
* * LED BI BO
31317 >BLOCK 81-1 Side2 (>BLK
81-1 S2)
81 O/U
Freq.S2
SP On
Of
f
* * LED BI BO
