Siemens 7SC80 - Page 757

No. Description Function Typ
e of
Info
rma
tion
Log Buffers Configurable in Matrix IEC 60870-5-103
Event Log ON/OFF
Trip (Fault) Log ON/OFF
Ground Fault Log ON/OFF
Marked in Oscill. Record
LED
Binary Input
Function Key
Relay
Chatter Suppression
Type
information number
Data Unit
General Interrogation
31318 >BLOCK 81-2 Side2 (>BLK
81-2 S2)
81 O/U
Freq.S2
SP On
Of
f
* * LED BI BO
31319 >BLOCK 81-3 Side2 (>BLK
81-3 S2)
81 O/U
Freq.S2
SP On
Of
f
* * LED BI BO
31320 >BLOCK 81-4 Side2 (>BLK
81-4 S2)
81 O/U
Freq.S2
SP On
Of
f
* * LED BI BO
31321 81 OFF Side2 (81 OFF S2) 81 O/U
Freq.S2
OUT On
Of
f
* * LED BO
31322 81 BLOCKED Side2 (81
BLOCKED S2 )
81 O/U
Freq.S2
OUT On
Of
f
On
Off
* LED BO
31323 81 ACTIVE Side2 (81
ACTIVE S2)
81 O/U
Freq.S2
OUT On
Of
f
* * LED BO
31324 81 Under Voltage Block
Side2 (81 UV Blk S2)
81 O/U
Freq.S2
OUT On
Of
f
On
Off
* LED BO
31325 81-1 picked up Side2
(81-1 PU S2)
81 O/U
Freq.S2
OUT * On
Off
* LED BO
31326 81-2 picked up Side2
(81-2 PU S2)
81 O/U
Freq.S2
OUT * On
Off
* LED BO
31327 81-3 picked up Side2
(81-3 PU S2)
81 O/U
Freq.S2
OUT * On
Off
* LED BO
31328 81-4 picked up Side2
(81-4 PU S2)
81 O/U
Freq.S2
OUT * On
Off
* LED BO
31329 81-1 TRIP Side2 (81-1
TRIP S2)
81 O/U
Freq.S2
OUT * On * LED BO
31330 81-2 TRIP Side2 (81-2
TRIP S2)
81 O/U
Freq.S2
OUT * On * LED BO
31331 81-3 TRIP Side2 (81-3
TRIP S2)
81 O/U
Freq.S2
OUT * On * LED BO
31332 81-4 TRIP Side2 (81-4
TRIP S2 )
81 O/U
Freq.S2
OUT * On * LED BO
31341 >Failure: Feeder VT Side2
(>FAIL:Fdr VT S2)
Meas-
urem.Super
v
SP On
Of
f
* * LED BI BO
31342 >Failure: Busbar VT Side2
(>FAIL:BUS VTS2)
Meas-
urem.Super
v
SP On
Of
f
* * LED BI BO
