No. Description Function IEC 60870-5-103 Configurable in
Matrix
Type
information number
Compatibility
Data Unit
Position
CFC
Control Display
Default Display
884 Power Factor Maximum (PF Max=) Min/Max meter - - - - - CFC CD
885 Power Factor Minimum (PF Min=) Min/Max meter - - - - - CFC CD
888 Pulsed Energy Wp (active)
(Wp(puls))
Energy 133 55 No 205 - CFC CD
889 Pulsed Energy Wq (reactive)
(Wq(puls))
Energy 133 56 No 205 - CFC CD
901 Power Factor (PF =) Measurement 134 157 No 9 14 CFC CD
924 Wp Forward (WpForward) Energy 133 51 No 205 - CFC CD
925 Wq Forward (WqForward) Energy 133 52 No 205 - CFC CD
928 Wp Reverse (WpReverse) Energy 133 53 No 205 - CFC CD
929 Wq Reverse (WqReverse) Energy 133 54 No 205 - CFC CD
963 I A demand (Ia dmd=) Demand meter - - - - - CFC CD
964 I B demand (Ib dmd=) Demand meter - - - - - CFC CD
965 I C demand (Ic dmd=) Demand meter - - - - - CFC CD
1058 Overload Meter Max (Θ/
ΘTrpMax=)
Min/Max meter - - - - - CFC CD
1059 Overload Meter Min (Θ/ΘTrpMin=) Min/Max meter - - - - - CFC CD
2161 External battery voltage (Vbat =) Measurement - - - - - CFC CD
2162 System temperature (SysTemp =) Measurement - - - - - CFC CD
2233 Vx = (Vx =) Measurement - - - - - CFC CD
2241 GPS Module Position Longitude
(deg, dec) (LON =)
Measurement - - - - - CFC CD
2242 GPS Module Position Latitude
(deg, dec) (LAT =)
Measurement - - - - - CFC CD
2243 GPS Module Position Altitude (m)
(ALT =)
Measurement - - - - - CFC CD
2244 GPS Module Position Altitude (ft)
(ALT =)
Measurement - - - - - CFC CD
2536 Number of received satellites =
(SAT count =)
Measurement - - - - - CFC CD
16004 Threshold Sum Current Exponen-
tiation (ΣI^x>)
SetPoint(Stat) - - - - - CFC
16009 Lower Threshold of CB Residual
Endurance (Resid.Endu. <)
SetPoint(Stat) - - - - - CFC
16017 Threshold Sum Squared Current
Integral (ΣI^2t>)
SetPoint(Stat) - - - - - CFC
16031 Angle between 3Vo and INsens.
(φ(3Vo,INs) =)
Measurement - - - - - CFC CD
30701 Pa (active power, phase A) (Pa =) Measurement - - - - - CFC CD
30702 Pb (active power, phase B) (Pb =) Measurement - - - - - CFC CD
30703 Pc (active power, phase C) (Pc =) Measurement - - - - - CFC CD
Functions, Settings, Information
F.5 Measured Values
