No. Description Function IEC 60870-5-103 Configurable in
Matrix
Type
information number
Compatibility
Data Unit
Position
CFC
Control Display
Default Display
30704 Qa (reactive power, phase A) (Qa
=)
Measurement - - - - - CFC CD
30705 Qb (reactive power, phase B) (Qb
=)
Measurement - - - - - CFC CD
30706 Qc (reactive power, phase C) (Qc
=)
Measurement - - - - - CFC CD
30707 Power Factor, phase A (PFa =) Measurement - - - - - CFC CD
30708 Power Factor, phase B (PFb =) Measurement - - - - - CFC CD
30709 Power Factor, phase C (PFc =) Measurement - - - - - CFC CD
31231 V2a-2b Min (V2a2bMin) Min/Max meter - - - - - CFC CD
31232 V2a-2b Max (V2a2bMax) Min/Max meter - - - - - CFC CD
31233 V2b-2c Min (V2b2cMin) Min/Max meter - - - - - CFC CD
31234 V2b-2c Max (V2b2cMax) Min/Max meter - - - - - CFC CD
31235 V2c-2a Min (V2c2aMin) Min/Max meter - - - - - CFC CD
31236 V2c-2a Max (V2c2aMax) Min/Max meter - - - - - CFC CD
31237 V2an Min (V2anMin=) Min/Max meter - - - - - CFC CD
31238 V2an Max (V2anMax=) Min/Max meter - - - - - CFC CD
31239 V2bn Min (V2bnMin=) Min/Max meter - - - - - CFC CD
31240 V2bn Max (V2bnMax=) Min/Max meter - - - - - CFC CD
31241 V2cn Min (V2cnMin=) Min/Max meter - - - - - CFC CD
31242 V2cn Max (V2cnMax=) Min/Max meter - - - - - CFC CD
31243 V1(positive
sequence)Volt.Minimum Side2
(V1MinS2=)
Min/Max meter - - - - - CFC CD
31244 V1(positive
sequence)Volt.Maximum Side2
(V1MaxS2=)
Min/Max meter - - - - - CFC CD
31245 V neutral Min Side2 (VnMinS2=) Min/Max meter - - - - - CFC CD
31246 V neutral Max Side2 (VnMaxS2=) Min/Max meter - - - - - CFC CD
31247 Frequency Minimum Side2
(fMinS2)
Min/Max meter - - - - - CFC CD
31248 Frequency Maximum Side2
(fMaxS2)
Min/Max meter - - - - - CFC CD
31249 V2a (V2a =) Measurement - - - - - CFC CD
31250 V2b (V2b =) Measurement - - - - - CFC CD
31251 V2c (V2c =) Measurement - - - - - CFC CD
31252 V2a-2b (V2a-2b=) Measurement - - - - - CFC CD
31253 V2b-2c (V2b-2c=) Measurement - - - - - CFC CD
31254 V2c-2a (V2c-2a=) Measurement - - - - - CFC CD
31255 VN Side2 (VNS2 =) Measurement - - - - - CFC CD
Functions, Settings, Information
F.5 Measured Values
SIPROTEC Compact, 7SC80, Manual 765
E50417-G1140-C486-A8, Edition 07.2017
