No. Description Function IEC 60870-5-103 Configurable in
Matrix
Type
information number
Compatibility
Data Unit
Position
CFC
Control Display
Default Display
31256 V1S2 (positive sequence Side2)
(V1S2 =)
Measurement - - - - - CFC CD
31257 V2S2 (negative sequence Side2)
(V2S2 =)
Measurement - - - - - CFC CD
31258 VoS2 (zero sequence Side2) (VoS2
=)
Measurement - - - - - CFC CD
31259 Frequency Side2 (FreqS2=) Measurement - - - - - CFC CD
31346 Angle Va (Phi Va = ) Measurement - - - - - CFC CD
31347 Angle Vb (Phi Vb =) Measurement - - - - - CFC CD
31348 Angle Vc (Phi Vc =) Measurement - - - - - CFC CD
31349 Angle Vab (Phi Va-b =) Measurement - - - - - CFC CD
31350 Angle Vbc (Phi Vb-c =) Measurement - - - - - CFC CD
31351 Angle Vca (Phi Vc-a =) Measurement - - - - - CFC CD
31352 Angle VN (Phi VN =) Measurement - - - - - CFC CD
31353 Angle Vo (Phi Vo =) Measurement - - - - - CFC CD
31354 Angle V1 (Phi V1 =) Measurement - - - - - CFC CD
31355 Angle V2 (Phi V2 =) Measurement - - - - - CFC CD
31356 Angle Vx (Phi Vx =) Measurement - - - - - CFC CD
31357 Angle Ia (Phi Ia =) Measurement - - - - - CFC CD
31358 Angle Ib (Phi Ib =) Measurement - - - - - CFC CD
31359 Angle Ic (Phi Ic =) Measurement - - - - - CFC CD
31360 Angle In (Phi In =) Measurement - - - - - CFC CD
31361 Angle 3Io (Phi 3Io =) Measurement - - - - - CFC CD
31362 Angle I1 (Phi I1 =) Measurement - - - - - CFC CD
31363 Angle I2 (Phi I2 =) Measurement - - - - - CFC CD
31364 Angle V2a (Phi V2a = ) Measurement - - - - - CFC CD
31365 Angle V2b (Phi V2b =) Measurement - - - - - CFC CD
31366 Angle V2c (Phi V2c =) Measurement - - - - - CFC CD
31367 Angle V2a-2b (Phi V2a-2b=) Measurement - - - - - CFC CD
31368 Angle V2b-2c (Phi V2b-2c=) Measurement - - - - - CFC CD
31369 Angle V2c-2a (Phi V2c-2a=) Measurement - - - - - CFC CD
31370 Angle VNS2 (Phi VNS2 =) Measurement - - - - - CFC CD
31371 Angle VoS2 (Phi VoS2 =) Measurement - - - - - CFC CD
31372 Angle V1S2 (Phi V1S2 =) Measurement - - - - - CFC CD
31373 Angle V2S2 (Phi V2S2 =) Measurement - - - - - CFC CD
31374 Angle INs (Phi INs =) Measurement - - - - - CFC CD
Functions, Settings, Information
F.5 Measured Values
766 SIPROTEC Compact, 7SC80, Manual
E50417-G1140-C486-A8, Edition 07.2017
