Chapter 5
Setup and Configuration
RUGGEDCOM WIN
User Guide
92 Configuring the WiMAX Radio
Figure88:Radio Settings Screen
2. Configure the following parameter(s) as required:
Parameter Description
Maximum Tx Power The maximum power in dBm that can be transmitted by the device. Any value can be
configured. However, the device will not exceed the following limits based on frequency
band and modulation.
Modulation
Band
BPSK, QPSK, QAM16 QAM64
1.4 GHz 27 dBm 24 dBm
1.8 GHz 27 dBm 24 dBm
2.3 GHz 27 dBm 24 dBm
2.5 GHz 27 dBm 24 dBm
3.5 GHz 27 dBm 24 dBm
4.9 GHz 24 dBm 21 dBm
5.1 GHz 24 dBm 21 dBm
5.8 GHz 21 dBm 21 dBm
Power Boost on Contention Synopsis: { On, Off }
Determines if transmission power is boosted on CDMA (Code Division Multiple
Accessbase) contention. When On, transmission power is boosted when another station
competes for the same bandwidth. When Off, transmission power is not boosted when
the SS detects contention. The default value is On.
3. Click Apply.
4. Reboot the device. For more information, refer to Section4.5, “Rebooting the Device” .
