RUGGEDCOM WIN
User Guide
Chapter 5
Setup and Configuration
Viewing Base Station Information 57
Figure49:System Functions Screen
2. Click Disconnect.
Section5.2.5
Viewing Base Station Information
To view information about the base station serving the device and information about neighboring base stations,
navigate to WiMAX» Mobility. The Mobility screen appears.
Figure50:Mobility Screen
The tables provide the following information:
Parameter Description
BSID Displays the MAC address of the base station.
Preamble Index Displays the base station’s preamble index.
Frequency Displays the base station frequency.
DL RSSI Displays the downlink RSSI (Received Signal Strength Indication).
DL CINR Displays the downlink carrier to interference and noise ratio, in dB.
