Chapter 5
Setup and Configuration
RUGGEDCOM WIN
User Guide
88 Enabling/Disabling Mini-Jumbo Frames
2. Select a row in the table.
3. Click Clear.
4. Click Apply.
Section5.17.4
Enabling/Disabling Mini-Jumbo Frames
The Maximum Transmission Unit (MTU) specifies the size of the largest data unit, in bytes, the base station will
transmit. The MTU value includes the L2 header and Cyclic Redundancy Check (CRC). The maximum MTU size is
1599 with mini-jumbo frames enabled.
NOTE
This setting is recommended for carrying Multiprotocol Label Switching (MPLS) traffic over WiMAX.
To enable or disable Mini-Jumbo Frames, do the following:
1. Navigate to Network» Ethernet Settings» MTU. The MTU screen appears.
Figure84:MTU Screen
2. Under Mini-jumbo frames support, select either Enable or Disable.
3. Click Apply.
4. Reboot the device. For more information, refer to Section4.5, “Rebooting the Device” .
Section5.17.5
Configuring the Access List
If the Access List function is enabled, only MAC Addresses in this list will be able to pass data. Pre-provisioned
entries can be added to the list in the Access List Table. Self-learned entries appear in the list automatically.
To configure the access list parameters, do the following:
1. Navigate to Network» Access List. The Access List screen appears.
